Carel WB000DG0F0 User Manual

64
ENG
UltraCella +0300083EN - rel. 1.5 - 07.02.2015
9.2 EVD Modules technical characteristics
Power supply voltage: 230 V~ (+10/-15%), 50/60 Hz; power: 4,5kW max.
NOTE: The maximum simultaneous current draw by all the loads connected to the controller and the
expansion modules must not exceed 20 A.
Classifi cation according to protection against
electric shock
Class II
Case plastic, dimensions 128x290x110 mm
Front protection rating with plastic case IP65
Fire resistance category category D
Cleaning the module front panel only use neutral detergents and water
Operating conditions -10T40°C, <90% r.H. non condensing
Storage conditions -20T60°C, <90% r.H. non condensing
PTI of insulating materials printed circuits 250, plastic and insulating materials 175
Tab. 9.b
9.3 Power Modules technical characteristics
Power supply voltage: 230 V~ (+10/-15%), 50/60 Hz; power: 4,5kW max.
NOTE: The maximum simultaneous current draw by all the loads connected to the controller and
the expansion modules must not exceed 20 A
Residual current circuit breaker In=20 A @30 °C, Id=300 mA
Power relay Rating: 30 A resistive, 240 Vac; 3HP 240 Vac
Classifi cation according to protection against electric shock Class II
Case plastic, dimensions 128x290x110 mm
Front protection rating with plastic case IP65
Fire resistance category Category D
Cleaning the module front panel only use neutral detergents and water
Operating conditions -10T40°C, <90% r.H. non condensing
Storage conditions -20T60°C, <90% r.H. non condensing
Tab. 9.c
9.4 3pH EVAPORATOR Modules technical characteristics
Power supply voltage: 400V~(+10/-15%), 50/60Hz, 3PH+N+T, Imax 25A
Classifi cation according to protection against electric shock Class I
Case plastic, dimensions 452x380x186 mm
Weight 8,7 Kg
Front protection rating with plastic case IP65
Cleaning the module front panel only use neutral detergents and water
Operating conditions -10T40°C, <90% r.H. non condensing
Storage conditions -20T60°C, <90% r.H. non condensing
Materials frontal cover in polycarbonate, retro box in technopolymer
Tab. 9.d
9.4.1 Electrical characteristics
Ultra 3PH Evaporator module 6kW Ultra 3PH Evaporator module 9kW
Code WT00E60N00 WT00E90N00
General
Main switch / general protection 4 poles magnetothermic 16A 6kA D 4 poles magnetothermic 25A 6KA D
Loads power supply 400V~(±10%), 50/60Hz, 3PH+N+T 400V~(±10%), 50/60Hz, 3PH+N+T
Insulating transformer PRI 230 Vac
SEC1 230 Vac 40VA
SEC2 24 Vac 35VA
Protection SEC by fuses
PRI 230 Vac
SEC1 230 Vac 40VA
SEC2 24 Vac 35VA
Protection SEC by fuses
Status and alarm indication By UltraCella By UltraCella
Input
Main defrost probe NTC 10kΩ NTC 10kΩ
Auxiliary evap. defrost probe NTC 10kΩ NTC 10kΩ
Clicson evaporator Present Present
Thermostat evaporator Present Present
Output
Condensing unit enabling / Solenoid valve 8A (AC1) / 2A (AC23) 1PH 8A (AC1) / 2A (AC23) 1PH
Defrost heaters 6kW, 9A (AC1) 3PH 9kW, 13A (AC1) 3PH
Evaporator fans 0,55kW, 1,5A* (AC23) 3PH
0…10Vdc
2kW, 5,7A* (AC23) 3PH
0…10Vdc
AUX1 output 16A (AC1) 1PH 16A (AC1) 1PH
Tab. 9.e
* Rating with cosφ=0,5;
With diff erent power factor, to calculate the rating consider the formula: I = P / (400 * √3 * cosφ) where P is the power in W
