Carel WB000DG0F0 User Manual

60
ENG
UltraCella +0300083EN - rel. 1.5 - 07.02.2015
ALARM TABLE
Cod. display
Alarm cause
Icon on the
display fl ashing
Display key
fl ashing
Alarm relay
Buzzer
Reset
PD valve
Compressor
Defrost
Evaporator Fans
Condenser fans
Continuous cycle
rE Virtual control probe fault ON ON automatic duty setting (c4) duty setting (c4) - - -
OFF
E0 Probe B1 fault ON ON automatic duty setting (c4) duty setting (c4) - - -
OFF
E1 Probe B2 fault ON ON automatic - - - - -
OFF
E2 Probe B3 fault ON ON automatic - - - - - -
E3 Probe B4 fault
ON ON automatic - - - - - -
E4 Probe B5 fault
ON ON automatic
--- NO OFF OFF automatic - - - - - -
LO Low temperature alarm -
ON ON automatic - - - - - -
HI High temperature alarm -
ON ON automatic - - - - - -
IA Immediate alarm from external contact -
ON ON automatic
duty setting (A6) duty setting (A6) OFF - - OFF
Pd Maximum pump down time alarm - ON ON autom. / manual
------
LP Low pressure alarm - ON ON
OFF OFF OFF - - -
AtS Autostart in pump down - ON ON autom. / manual
------
CHt High condenser temperature alarm - ON ON manual
OFF OFF - - OFF -
dor Door open too long alarm - ON ON automatic - - - - - -
Etc Real time clock is broken
ON ON
autom. / manual - - - - - -
EE EEprom error, unit parameters
ON ON
automatic - - - - - -
EF Eeprom error, operating parameters
ON ON
automatic - - - - - -
Ed1,
Ed2
Defrost ended by timeout -
ON ON automatic - - - - - -
HA HACCP alarm, HA type -
+
ON ON
manual
------
HF HACCP alarm, HF type -
+
ON ON
manual
------
LoG Download recorded temperature fault OFF ON automatic
------
uPL Parameters upload fault - OFF ON automatic
------
dnL Parameters download fault - OFF ON automatic
------
ALM Recorded alarms download fault - OFF ON automatic
------
SHA Low superheat protection
ON ON
automatic
------
SOF Software update fault - ON ON automatico OFF OFF OFF - - -
LOA LOP protection
ON ON
automatic
OFF OFF OFF - - -
MOA MOP protection
ON ON
automatic
OFF OFF OFF - - -
EEA Valve motor fault
ON ON
automatic
OFF OFF OFF - - -
LSA Threshold and timeout exceeded
ON ON
automatic
OFF OFF OFF - - -
Hit High condensing temperature protection activated
ON ON
automatic
OFF OFF OFF
---
ES1 Probe S1 fault or set point exceeded
ON ON
automatic
OFF OFF OFF
---
ES2 Probe S2 fault or set point exceeded
ON ON
automatic
OFF OFF OFF
---
ES3 Probe S3 fault or set point exceeded
ON ON
automatic
OFF OFF OFF
---
ES4 Probe S4 fault or set point exceeded
ON ON
automatic
OFF OFF OFF
---
bAt
Battery discharged or faulty or electrical connection
interrupted
ON ON
automatic
OFF OFF OFF
---
EEE Operating and/or parameter EEPROM error
ON ON
automatic
OFF OFF OFF
---
EIC Valve not closed completely
ON ON
automatic
OFF OFF OFF
---
