Carlson Surveyor 2 - Initial Setup Procedures

BATTERY COMPARTMENT AND CARD SLOTS
1. Battery Door, Screws
2. Battery Pack
3. Mini SIM Card Slot
4. Micro SD/SDHC Card Slot
5. Battery Compartment
6. Connector Protector
CONNECTOR MODULE
1. Connector Module
2. USB Client, Micro
3. Microphone/Speaker Jack
4. USB Host, Full Size
5. 9-pin Serial Port
6. Docking Pin Contacts
7. Hand strap Attachment Point
8. 12-24V DC Jack
PERFORM INITIAL TASKS
When you receive your Surveyor2, perform the tasks outlined in this section before first use.
