3G Data Modem (Geo model with cell modem): Shows the on/off state of the optional cellular
modem.
Flashlight: Shows the on/dim/off state of flashlight feature (included with camera).
GADGET COLOR INDICATORS
Wi-Fi, Bluetooth, GPS and 3G data modem gadgets indicate status using these colors:
Yellow: Partial state (getting satellite fix, etc.)
Green: Active and available
Blue: Notification state (on or connected)
Red: Error state, powering up or down, no GPS/GNSS fix, or unavailable (3G data modem is red
when power is changing from on/off. Wi-Fi is red when an access point is available but not
connected.)
FAVORITES BAR
The favorites bar consists of shortcuts to specific applications. It is located below the dashboard
when the screen is in portrait mode and to the side of the dashboard when it is in landscape
mode. Tap on a shortcut icon to launch an application.
Note: When SurvCE is installed on the Surveyor2, it will automatically be placed in the bottom
(landscape mode) shortcut.
