Waypoint Settings: Set up the waypoint file naming scheme, including the waypoint prefix,
increment step size, and current value. For example, if the waypoint prefix is Point,
increment step size is 10, current value is 100, and default file type is .kml, file names
would be Point110.kml, Point120.kml, Point130.kml, etc.) Also select the number of
points to average. The default is 1.
Track Settings: Set up the track file naming scheme (see Waypoint Settings). You can
select a minimum time and minimum distance needed before a point is collected. If both
are enabled, both conditions must be met before a point is added to a track. You can
disable suspend when track points are being collected.
Audio Notifications: You can turn on notifications for waypoint arrival, waypoint collected,
and track point collected.
Some settings can be customized for a particular waypoint or track using edit on the data
collection screens.
VIEW SIGNAL STRENGTH AND NMEA STRINGS
View the strength of satellites being used in a fix (shown in green) by swiping the left side of the
display (where position is shown) on the JSNav Home screen to the right. View the NMEA strings
that are coming in through the GNSS receiver by swiping the same area to the left. Strings can be
saved to a file.
COLLECT WAYPOINT DATA
From the main JSNav screen select the waypoint icon to open the Collect Waypoint screen.
To collect a waypoint, select the waypoint icon at the bottom of the screen. Position
information for the waypoint is recorded.
Select the edit icon to add or edit the name, description, notes, and file type for this waypoint.
