3-CONTROLS/INSTRUMENTS
Safetyvalves(optional)
Servicespecications
CheckbyyourCASECONSTRUCTIONDealer:Every6months
Theroleofthesafetyvalveistostoptheattachmentfromdroppingduetovalvespoolleakageinneutralpositionor
intheeventofalineorhoseaccidentallybreaking.Inthelatterevent,theyalsoensurethattheattachmentmaybe
loweredgentlytotheground.
Onboomcylinder
SMIL13CEX2902AB1
Onarmcylinder
SMIL13CEX2903AB2
Optionaltoolsupplyvalves
Locatedoneachsideoftheendofthearm,thesevalves
areusedtoensureoilsupplytooptionaltools,forexam-
ple,hydraulicbreakers,etc.Thesevalveshavetwoposi-
tions,open/closed.
SMIL13CEX2655AB1
3-53
