6-MAINTENANCE

Greasepoints(Easymaintenancesystem)

NOTICE:ifthefollowinglinkagepointarenotequippedwithoriginalparts,thispointmustbegreasedevery50hours.

Usingagreasegun,injectgreaseofthespecied

typeinthegreasepointsshowningures:

•

Boomcylindertoppin

SMIL13CEX2970AB1

•

Boomcylinderbottompin

SMIL13CEX2971AB2
