3-CONTROLS/INSTRUMENTS

REARWARDCONTROLS

Fusebox

Locatedontheleft-handsite,behindtheoperator'sseat.

SMIL13CEX2628AB1

Removethecoverofthefusebox.

SMIL13CEX2629AB2

Magazinerack

Locatedontheright-handside,behindtheoperator’s

seat.

SMIL13CEX2630AB1

3-39
