CASE CONSTRUCTION CX80C - Quick Coupler (Optional)

4-OPERATINGINSTRUCTIONS
Quickcoupler(optional)
WARNING
Crushinghazard!
Neverputyourhandsinsidethequickcoupler
whentheengineisrunning.Turnofftheen-
gineandwaitforallmovementtostop.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0252A
Installthequickcoupleronthedipperandontheconnect-
ingrodusingtheCASECONSTRUCTIONlinkagepins(1)
suppliedandthenmakethesupplylineconnections.
NOTICE:Thequickcouplercanbeusedinconjunction
withhydraulicbreakers,butisnotdesignedtowithstand
excessivevibrationoverlongperiodsofthetime.Itis
thereforerecommendedtoremovethequickcoupler,to
reducetheriskofprematurewear,failuresorbreakage.If
youdodecidetouseahydraulicbreaker,alwaysorientate
thebreakertowardsthemachineandneveruseitasa
lever,asthestresswouldbebornebythequickcoupler
cylinder.
SMIL13CEX2695AB1
Quicktoolinstallationandremoval
WARNING
Hazardtobystanders!
ALWAYSmakesuretheworkareaisclear
ofbystandersanddomesticanimalsbefore
startingthisprocedure.Knowthefullarea
ofmovementofthemachine.Donotpermit
anyonetoentertheareaofmovementduring
thisprocedure.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0245A
NOTICE:Thisquickcouplerisdesignedtobeusedwith
CASECONSTRUCTIONbuckets.Thisbeingsaid,other
bucketsmaybeused,providedthediameterofthepins
andthewidthbetweenthebucketlugsaremodiedto
meetthedimensionsneededtotthequickcoupler
(pins,washers,bushings,etc.).ConsultyourCASE
CONSTRUCTIONDealer.
Installation
1.Makesurethetooltobeinstalledislayingsafelyon
at,levelgroundandthatitisttedwiththepinssup-
pliedwiththequickcoupler.
