Batterydisconnectswitch
Thebatterydisconnectswitchcanbeaccessedbyopen-
ingtheleft-handdoorofthemachine.
SetthebatterydisconnectswitchtoI(ONposition)for
otherthanlongtermstorageorservicingtheelectrical
system
SMIL13CEX2959AB1
I(ONposition):insertthekeyandturnitclockwiseto
connecttheelectricalcircuits.Beforestartingtheengine,
turnthebatterydisconnectswitchtoI.
O(OFFposition):turnthekeycounterclockwisetocutoff
theelectricalcircuits.Alwayssetthebatterydisconnect
switchtoOforlongtermstorageorservicingtheelectrical
systemthenremovethekey.
NOTE:whentheswitchisturnedtoO(OFFposition),all
electricalcircuitsarecutoff.
NOTICE:neverturnthebatterydisconnectswitchtoO
(OFFposition)withtheenginerunning.Thiscoulddam-
agetheelectricalsystem.
NOTICE:neverturnthebatterydisconnectswitchtoO
(OFFposition)within1minafterthestarterkeyisturned
off.Thecomputerprogramforthehydraulicexcavator
systemdoesnotcompletecorrectly.
SMIL13CEX2882BB2
