6-MAINTENANCE

Tracks

NOTICE:ifthetracksaretootight,theywearquickly.Iftracksarenottightenough,theywearquicklyandthelinks

cancatchonthesprocketwheelorslideofftheidlerwheelorthesprocketwheel.Cleanthetracksafterwork.

WARNING

Tip-overhazard!

Onlyraisethetrackaslittleasnecessary.

Failuretocomplycouldresultindeathor

seriousinjury.

W0276A

Tocheckthetrackstension,proceedasfollows:

1.Swingtheupperstructuretoastraightangle

relativetotheundercarriage.Lowertheattach-

menttotheground,thenlowertheboomuntil

thetrackisraisedofftheground.Placeablock

undertheundercarriageandraisetheattach-

mentofftheground.

SMIL13CEX2978AB1

2.Turntheenginethrottlevolumetothemaxi-

mumspeedposition.

SMIL13CEX2715AB2

3.Setthetravelspeedselectortohighspeed.

SMIL13CEX2719AB3

6-26
