CASE CONSTRUCTION CX80C - Auxiliary Hydraulic Circuits

4-OPERATINGINSTRUCTIONS
Auxiliaryhydrauliccircuits
ConsultyourCASECONSTRUCTIONDealertoselecttheoptionalaccessorycompatiblewithyourmachineandto
correctlyadjusttheowrequiredforitsuse.
NOTICE:topreventfailureordamagetothetool,makesurethatyouselectthecorrectcircuitcongurationandow
rateforthetool.
Hydraulicbreakerorhighowhydrauliccircuits(optional)
Yourmachinehastwotypesofauxiliaryhydrauliccircuit.Onecircuitisforsingleowequipment,suchashydraulic
breakers.Thesecondtypeofcircuitisintendedforusewithsingleowordoubleowwithcontinuousoworforuse
withdoubleowsuchasdemolitionconcretecrushers,etc.
1.Makethenecessarytoolconnectionsandthen,using
ahexagonalwrench,openthesupplyvalveslocated
atthetipofthearm,left-handandright-handside.
SMIL13CEX2709AB1
2.Switch(1)locatedonthefrontright-handconsole,
correspondingtothehydraulicbreaker.Eachtime
theswitch(1)ispressed,itswitchesbetweenbucket,
breaker,andcrusher.
SMIL13CEX2710AB2
3.Theiconoftheaccessoryassociatedtoeachtypeof
owisdisplayedonthescreen.
NOTICE:inordertopreventbreakdownofanddamageto
thetool,alwaysselectthecircuitconguration,ow,and
pressurethatarecorrectforthetool.
SMIL13CEX2711AB3
4-25
