3-CONTROLS/INSTRUMENTS

Rearviewmirrors

Mirrorinstallationposition

SMIL13CEX2634EB1

Mirroradjustment

WARNING

Avoidinjuryand/ormachinedamage!

Keepthemirrorscleanandproperlyadjusted.

Failuretocomplycouldresultindeathorseriousinjury.

W1078A

SMIL13CEX2635EB2

A,B,C,D:reectedrangeineachmirror.

3-42
