CASE CONSTRUCTION CX80C - Right-Hand Side Controls

3-CONTROLS/INSTRUMENTS
RIGHT-HANDSIDECONTROLS
Right-handsidecontrols
SMIL13CEX2868EB1
1.Starterswitch
Thisswitchhasfourpositions,ON(contact),START
(engineignition),OFF(engineshut-down)andACC
(accessorycurrentsupply).
NOTICE:whentheignitionkeyisinON(contact)posi-
tion,iftheanti-theftprotectionhasbeenprogrammed,
thenitwillbenecessarytoenterthecode.Themes-
sage"Password"willbedisplayed.Refertopage4-1.
NOTE:thiskeyisalsousedtolockthecabdoor,the
enginehood,thefrontstoragecompartment,theside
doorsandthefueltankcap.
2.Engineaccelerationbuttonandworkingmodeselec-
tor
Thisbuttonenablesanincreaseorreductioninthe
enginespeed.Thisbuttoniscoupledwiththethree
workingmodeselector:
ModeA(automatic)whentheenergyoutputhaspri-
ority.
Inthismode,thebalancebetweenthespeedanden-
ergyoutputiscontrolledforeachmovementofthe
controls.
ModeHfordifcultexcavationworkoriftheloadin-
creases,andmodeSPwhentheoutputhaspriority.
Eachselectedmode(A,HorSP)isdisplayedonthe
screen.
NOTE:toselecttheSPmode,operatetheindexing
pinwhilerotatingtheaccelerationbuttontotheright.
NOTE:ifthereisnochangeinenginespeed,press
andreleasetheengineautomaticidlespeedselector.
3.Engineidlespeedselector
Thiscontrolenablesautomaticengineidlewithoutop-
eratingthethrottlebutton.Toselectidlespeed,press
andreleasethecontrolfortheengineautomatically
togointoidlespeed;the"Engineidling"iconwillap-
pearonthemessagescreens.Whenthecontrolis
pressedandreleasedoncemoretheenginewillre-
verttoitsoriginalspeedandtheicononthesystems
displaypanelwilldisappear.
4.Optionswitch
5.Wiperswitch
Whenthisswitchispressed,thewipermoves.
6.Travelcautionalarmswitch
WiththeswitchintheCONTposition,analarmsounds
whenthetravelcontrolisoperated.Withtheswitch
intheAUTOOFFposition,analarmsoundsfor10s
whenthetravelcontrolisoperated.
7.Cabradiocompartment
Thispreequippedcompartmentisprovidedforin-
stallinga24Vvehicleradio.Fordetailsontheve-
hicleradiooperation,readtheoperator’smanualthat
comeswiththecarradio.
8.AUX(externalinput)
Duringradioreception,youcanconnectacommer-
cially-availableaudioportableunitandlistentomusic,
etc.
3-34
