CASE CONSTRUCTION CX80C - Every 2000 Hours; Hydraulic Suction Filter

6-MAINTENANCE
Every2000hours
Hydraulicsuctionlter
NOTICE:whenusingthehydraulicbreaker,reducetheintervalofthesuctionltercleaning.Refertopage6-12.
WARNING
Burnhazard!
Beforeperforminganyserviceonthehy-
draulicsystem,youmustallowittocool.
Hydraulicuidtemperatureshouldnot
exceed40°C(104°F).
Failuretocomplycouldresultindeathor
seriousinjury.
W0241A
WARNING
Pressurizedsystem!
Neverattempttodrainuidsorremovel-
terswhentheengineisrunning.Turnoff
theengineandrelieveallpressurefrom
pressurizedsystemsbeforeservicingthe
machine.
Failuretocomplycouldresultindeathor
seriousinjury.
W0905A
Tocleanthesuctionlterproceedasfollows:
1.Releaseallpressureinthehydraulicreservoir.
Refertopage6-11.
2.Cleanthetopofthehydraulicreservoirand
cleanthesuctionltercover.
3.Removethesuctionlterrodassemblycover
(1)andO-ring(2).
4.Removethesuctionlter(3)andcleanwith
solvent.Drytheltercompletelyandcheckthat
thereisnodamage.Ifthereisanydamageto
thesurface,replaceitwithanewlter.
5.InstallthenewO-ring(2),theninstallthesuc-
tionlter(3)androdassembly.
6.Installthecover(1).
7.Checkthehydraulicoillevelandtopupasnec-
essary.RefertopageOillevelindicator-
Check.
NOTICE:ifmetalparticlesarefoundintheoldlter,consult
yourCASECONSTRUCTIONDealer.
NOTICE:replacethesuctionlterevery5000hoursofop-
erationorwhenthehydraulicoilischanged.
SMIL13CEX2795AB1
SMIL13CEX2796BB2
6-59
