CASE CONSTRUCTION CX80C - Dozer Blade Control Lever; Boom Swing Operating Pedal

3-CONTROLS/INSTRUMENTS
Dozerbladecontrollever
Checkthesafetyofthemachinesurroundingbefore
operatetheblade.Bladeisforlightdutyworksuchas
pushingsoftdirtormudonly.
•
Donotpushdownhardonthebladeoritmaycause
damagetothebladeandfoot.
•
Toavoiddamagetotheblade,donotsideloadthe
blade.
•
Becarefulasapplyingaloadtoonesideoftheblade
canbreaktheblade.
•
Whenusingthebladetosupportthefrontofthema-
chineduringoperation,ensurethatthebladeisrmly
supportedoverthefulllengthoftheblade.
•
Becarefulnottobreakthebladeatlocationswithmany
rocks.Thiswillpreventdamagetotheblade.
SMIL13CEX2945AB1
Boomswingoperatingpedal
WARNING
Unexpectedmachinemovement!
ALWAYSlocktheauxiliarypedalswhennotin
use.
Failuretocomplycouldresultindeathorse-
riousinjury.
W0222A
Toswingtheboomright,pressthepedalindirection(a)
Toswingtheboomleft,pressthepedalindirection(b)
NOTICE:whentheattachmentisfullyrotatedtotheleft,
thebucketcomesclosetotheoperator’scab,themirror
andtheheadguard.Whenchangingthebucket,conrm
thatnointerferencewiththebucketwillbefound.Ifthe
bucketcaninterfereswithsomething,provideoperators
withacautionplatewarningthatitcanbeinterfered.
SMIL13CEX2946AB1
3-10
