CASE CONSTRUCTION CX80C - Pilot Line Filter

6-MAINTENANCE
Pilotlinelter
NOTICE:whenusingthehydraulicbreaker,reducetheintervalofthepilotlterreplacement.Refertopage6-12.
WARNING
Burnhazard!
Beforeperforminganyserviceonthehy-
draulicsystem,youmustallowittocool.
Hydraulicuidtemperatureshouldnot
exceed40°C(104°F).
Failuretocomplycouldresultindeathor
seriousinjury.
W0241A
WARNING
Pressurizedsystem!
Neverattempttodrainuidsorremovel-
terswhentheengineisrunning.Turnoff
theengineandrelieveallpressurefrom
pressurizedsystemsbeforeservicingthe
machine.
Failuretocomplycouldresultindeathor
seriousinjury.
W0905A
Toreplacethepilotlterproceedasfollows:
1.Releaseallpressureinthehydraulicreservoir.
Refertopage6-11
2.Fitthewrenchtothebottomofthelterandturn
it.
3.Coatthesealofthenewlterwithcleanoil.
4.Installanewlter.Turnthelteruntiltheseal
comesintocontactwiththelterhead,then
tightenbyanextra1/3turnbyhand.
NOTICE:ifmetalparticlesarefoundintheoldlter,consult
yourCASECONSTRUCTIONDealer.
SMIL13CEX2800AB1
6-61
