CASE CONSTRUCTION CX80C - Gate Lock Lever; Cab Internal Lighting; Emergency Exit Hammer

3-CONTROLS/INSTRUMENTS
Gatelocklever
Thegatelocklever(safetybar)(1)preventstheopera-
torfromleavingtheoperator'sseatwithoutreturningthe
controlarmtoitscorrectposition.Theoperatorcanleave
theoperator'sseatonlyafterraisingthegatelocklever
(safetybar)andtheleftsideconsole.
Tomakeitpossibletooperatetheattachment,travel,and
swingfunctionsagain,lowerthegatelocklever(safety
bar)(1).
NOTE:tostarttheengine,thegatelocklever(safetybar)
(1)mustbemovedinraisedposition.Theenginecannot
bestartedwiththegatelocklever(safetybar)inlower
position.
SMIL13CEX2838AB1
Cabinternallighting
Thelightislocatedontheleft-handcabuprightandis
controlledbyathreepositionswitchsetinthelampbase.
Positions:“On”(continuousoperation),“Off”(shut-
down)andintermediatepositiongoesoff30safter
closingthedoor.
NOTICE:makesurethatthelightsareswitchedoffafter
use,otherwisethebatteriesmaybecomedischarged.
NOTE:toreplacethebulbrefertopage6-73.
SMIL13CEX2620AB1
Emergencyexithammer
Locatedontheleft-handcab,usethehammer(1)tobreak
therearwindow,andthenpushthewindowstronglyand
escapeoutside.
ConsultyourCASECONSTRUCTIONdealerforwindow
installation.
NOTICE:Donotbreaktherearwindowexceptwhenitis
absolutelynecessary,suchastoescapeinanemergency.
NOTICE:Donotplaceanythinginfrontofthewindow.
Doingsomayobstructanemergencyescape.
SMIL13CEX2621AB1
3-32
