3-CONTROLS/INSTRUMENTS

Usethestarterswitchkeytoclosethehood.

SMIL13CEX2648AB4

Lowerpanels

WARNING

Movingparts!

Makesurethelowerpanelsareproperly

closedbeforedrivingthemachine.

Failuretocomplycouldresultindeathorse-

riousinjury.

W0910A

Locatedundertheupperstructureframe,thesepanels

provideaccesstocertainmachinecomponents.

NOTICE:Donotrunthemachinewiththepanelsre-

moved.

SMIL13CEX2649AB1

3-49
