CASE CONSTRUCTION CX80C - Tool Quick Coupler Locking and Unlocking Control Switch (Optional); Sliding Windows on Door

3-CONTROLS/INSTRUMENTS
Toolquickcouplerlockingandunlockingcontrolswitch(Optional)
Thisswitchislocatedontheleft-handcontrolarm.
Tounlockpullthelockingpin(1)towardsyouandsimul-
taneouslypressthetopoftheswitch.Inthisposition,the
audiblealarmdevicesoundsandthetoolcanbeinstalled
orremoved.
NOTE:Forsafetyreasons,theswitchcannotbeoperated
bysimplypressingthetop.
Tolock,pressthebottomoftheswitch.Inthisposition,
theaudiblealarmdevicewillceasetofunction.
NOTE:Whenlocking,itisnotnecessarytooperatethe
lockingpin(1).
NOTE:Eachtimeyouchangeatool,besuretoplacethe
switchinlockedposition.
SMIL13CEX2622AB1
Slidingwindowsondoor
Whenthelocksarereleased,thewindowscanbeopened
andclosedtotheleftorrightasrequired.
SMIL13CEX2623AB1
3-33
