ACCESSTOOPERATOR'SPLATFORM
Frame-Access/Exit
Cabdoor
CAUTION
Pinchhazard!
Becarefulnottogetyourhand,clothes,etc.caughtinthedoorwhenclosingit.
Failuretocomplycouldresultinminorormoderateinjury.
C0046A
Toopenthedoor,usethehandle(1)fromtheoutsideand
usethehandle(2)fromtheinside.
SMIL13CEX2564AB1
SMIL13CEX2565AB2
Thedoorcanbelatchedincompletelyopenposition.T o
unlatchthedoor,tiltthelever(3)downward.
NOTICE:donotleavethedoorajar.Fixitinalatched
position.
NOTICE:whenseatedintheoperator’scompartment,
withtheenginerunning,makesurethatyoudonotoper-
atetheleft-handcontrolleverinadvertentlywhenunlock-
ingthedoor.Topreventanyincident,alwaysraisethe
gatelocklever.
SMIL13CEX2566AB3
