4-OPERATINGINSTRUCTIONS

Operatingthebackhoebucket

Filling

Fillthebackhoebucketbymanoeuvringthedipper.Keepthebottomofthebackhoebucketparalleltothecut.The

backhoebucketteethandblademustcutthegroundlikethebladeofaknife.Thedepthofdigvariesdependingon

thetypeofmaterial.

Excavatingmethod

SMIL13CEX2693EA2

SMIL13CEX2694EB3

1.Correct

2.Incorrect.Thebackhoebucketwilldiginandcauseastall.

3.Incorrect.Thebackhoebucketispushedupwards.Thiswillalsoincreasethecycletime.

4-15
