4-OPERATINGINSTRUCTIONS

4.Usetheproportionalswitchtooperatetheconcrete

crusher.

NOTE:topreventfailureordamagetothetool,makesure

thatyouselectthecorrectcircuitcongurationandow

rateandpressureforthetool.

NOTICE:inbucketmode,donotcarryoutoperationus-

ingauxiliaryline.Ifyoudothat,thewarningmessage

“Auxiliarysetuprequired”willbedisplayedwithintermit-

tentwhistlesound.Stopoperationimmediatelyandcarry

outauxiliarysetup.

SMIL13CEX2583BA8

4-28
