5-TRANSPORTOPERATIONS

Retracttheattachment,bucketanddippercylindersfully

extendedthenplacetheattachmentontheground.Shut-

downtheengineandleavetheoperator’scompartment.

NOTICE:beforehandlingthemachine,makesurethe

slingsareinperfectconditionandthattheyarecapable

ofsupportingtheweightofthemachine.(Refertopage

Weight).

NOTICE:itisimperativetousetheslingpointsindicated

onthemachinedecals.(RefertopageSafetysigns).

NOTICE:themachinemustbehandledveryslowlyand

horizontally.

SMIL13CEX2953AB1

SMIL13CEX2954BB2

5-8
