6-MAINTENANCE

•

Bucketlinkages

NOTE:ifatoolotherthanthebucket(forexample,the

hydraulichammer)isinstalled,thesepointsmustbelubri-

catedevery10h.

SMIL13CEX2962AB2

SMIL13CEX2963AB3

•

Armlink/connectingrod

SMIL13CEX2964AB4

•

Bucketcylinderbottompin

SMIL13CEX2965AB5

6-20
