Quickcoupler(Optional)
Dimensionsneededtotthequickcoupler
Bucketpindiameter50mm(1.97in)
Widthbetweenlugs
176mm(6.9in)
Minimumdistancebetweenbucketcentres
290mm(11.4in)
Maximumdistancebetweenbucketcentres
312mm(12.3in)
NOTICE:thequickcouplerdescribedinthismanualisdesignedtobeusedwithCASECONSTRUCTIONbuckets.
Thisbeingsaid,otherbucketsmaybeused,providedthediameterofthepinsandthewidthbetweenthebucketlugs
aremodiedtomeetthedimensionsneededtotthequickcoupler(pins,washers,bushings,etc.).Consultyour
CASECONSTRUCTIONDealer.
Weight:100kg(220.5lb)
Overalldimensions
SMIL13CEX2503EB2
(A)610mm(24.02in)
(B)378mm(14.88in)
(C)312mm(12.28in)
Boomandarm
Boomlength
3.50m(137.80in)
Armlength
1.69m(66.54in)2.19m(86.22in)
