CASE CONSTRUCTION CX80C

To Next Page

To Previous Page

2-SAFETYINFORMATION

Illustrationofdecals

Tableofsafetyprecautions

Partnumber:KHP19130

SMIL13CEX2522FB5

Toolinterference

Thisdecaldrawsattentiontothefactthat,incertainpo-

sitions,therecanbeinterferenceofthetoolbetweenthe

attachmentandtheoperator'scompartment.Alwaysob-

serveaminimumsafetydistancebetweenthetoolandthe

operator'scompartment(incaseofswingingoraccidental

movements).

SMIL13CEX2523AB6

2-18
