2-SAFETYINFORMATION
Parkingthemachine
Thisdecalshowsthat,beforeleavingtheoperator’scom-
partment,thebucketandthedozerblade(ifequipped)
mustbeloweredtotheground,thegatelocklevermust
beactivated,theenginestoppedandtheignitionkeyre-
movedinordertopreventanymovementofthemachine.
SMIL13CEX2528AB11
Functionofthecontrollevers
Thisdecalshowsthefunctionoftheleft-handandright-
handcontrollevers.
Partnumber:KHP17370
SMIL13CEX2529AB12
Partnumber:KHP17380(2wayfunctionofthecontrol,
option)
SMIL13CEX2845AB13
Partnumber:KHP21120(withright-handoption)
7B236A9F14
2-20
