3-CONTROLS/INSTRUMENTS
Heightandweightadjustmentsection
Turningthedial(1)counter-clockwisesoftensthesuspen-
sion.
Turningthedial(1)clockwisehardensthesuspension.
SMIL13CEX2570AB2
Forwardandbackpositionadjustmentsec-
tion
Withtheslidelever(2)pulledup,movetheseatforward
andback.Whentheseatreachestheproperposition,
releasetheslidelever(2).
SMIL13CEX2571AB3
Armrestangleadjustmentsection
Raisethearmrest,turnthedial(3)toadjusttheangle,
thenlowerthearmrest.
SMIL13CEX2572AB4
Seat/controlarmassemblyforward-back
adjustmentsection
Pulluptheslidelever(4)andmovetheseat/controlarm
assemblytothedesiredposition,thenreleasetheslide
lever(4).
SMIL13CEX2573AB5
