MirrorC(Rightsideofhouse)
Wheninstallingthismirror,adjustitsothattherightrear
endisvisiblefromtheoperator'sseat.
•
Installthemirrorsatthepositionsinthegureonthe
right.
L:461mm(18.150in)
Bolttighteningtorque:
35.2-42.2N·m(25.962-31.125lbft).
•
Adjustthismirrorsothatthesideofthemachinereects
inthemirrorasinthegureontheright.
Tighteningtorque:Tighteningboltsonthemirror:
4.5-5.5N·m(3.3-4.1lbft).
SMIL13CEX2640AB7
SMIL13CEX2641AA8
MirrorD(Cabrear)
Wheninstallingthismirror,adjustitsothattherear
sectionofthemachineisvisiblefromtheoperator'sseat.
•
Installthemirrorsatthepositionsinthegureonthe
right.
L:90mm(3.543in).
•
Adjustthismirrorsothattherearofthemachinereects
inthemirrorasinthegureontheright.
Tighteningtorque:Tighteningboltsonthemirror:
4.5-5.5N·m(3.3-4.1lbft).
SMIL13CEX2642AB9
SMIL13CEX2643AA10
