Cedar Summit F25720 - Page 36

Hardware
B: Place (031) Access Board from Step 3, Part 1 against (021) Right Access and (024) Rock Rail and ush to
the top then attach with 4 (S20) #8 x 1-3/8” Wood Screws. (g. 10.3 and 10.4)
Fig. 10.3
Fig. 10.4
021
024
Step 10: Attach Access Ladder/Rockwall Assembly
Part 2
4 x #8 x 1-3/8” Wood Screw
Flush
031
S20
S20
