Local Operation
Then the display will go to the first editing page again.
4.6.2 Setup of Sine Wave Dynamic Function
In the page of Advance function, turn the Rotary knob to change the display value to 2, then
press key into the page of Sine Wave Dynamic Function.
[ ADVANCE ]
1.TIMING
2.SINE WAVE DYNA
3.OCP TEST
4.AUTO SEQUENCES
[ ADVANCE ]
5. MPP TRACKER
6. USER DEF. WAVE
[ SINE WAVE DYNA ]
0.0000 mV+
0.0000 mV-
Press key in SINE WAVE DYNA screen can set the parameters required for I_DC,
I_AC and FREQ. I_DC is the DC bias current and I_AC is the peak to peak current
generated based on the I_DC. The setting range of FREQ is 0.01Hz~20000Hz.
When setting the I_DC and I_AC, beware the minimum current cannot be lower than 0A
otherwise the “Out Of Range!!” message will prompt on the panel.
[ SINE WAVE DYNA ]
I_DC :02.000A
I_AC :01.000A
FERQ :060.00HZ
4.6.3 Setup of OCP Test Function
In the page of Advance function, turn the Rotary knob to change the display value to 3, then
press key into the page of OCP Test Function, the VFD displays OCP test Function.
