Programmable DC Electronic Load 63600 Series Operation & Programming Manual
(0.8 V).
■ Selective voltage and current ranges.
■ Remote sensing capability.
■ 100 sets of memories to save/recall user-definable setups.
■ 10 sets of programs to link files for automatic test.
■ 16-bit A/D converter with precision measurement.
■ Short circuit simulation.
■ Master/Slave parallel control mode, allow synchronous load control under static and
dynamic loading mode
■ Automatic GO/NG inspection to examine if UUT within spec.
■ Independent GO/NG signals for each channel.
■ Protection Over voltage, Over current, Overpower, Over temperature, Reverse polarity.
1.4 Specifications
Mainframe: 63600-5
AC input range: 1φ 100~115VAC ±10%V
LN
Auto range
1φ 200~230VAC ±10%V
LN
Auto range
Fuse: 5A, 250V
Frequency: 47 to 63 Hz
Maximum VA: 300VA
Weight: 15.6kg / 34.39lbs
Dimension:
Width: 447 mm / 17.6 inch
Height: 177 mm / 7.0 inch (without foot stand)
194.8 mm / 7.7 inch (with foot stand)
Depth: 554.2 mm / 21.8 inch (with Load Module)
Mainframe: 63601-5
AC input range: 1φ 100~240VAC ±10%V
LN
Fuse: 10A, 250V
Frequency: 47 to 63 Hz
Maximum VA: 1000VA
Weight: 13.6kg / 29.98lbs.
Dimension:
Width: 447 mm / 17.6 inch
Height: 177 mm / 7.0 inch (without foot stand)
194.8 mm / 7.7 inch (with foot stand)
Depth: 554.2 mm / 21.8 inch (with Load Module)
The detail specifications of Load are listed in the next page.
This equipment is not intended for performing measurements on CAT II,
III or IV.
1. The equipment is for indoor use only.
2. The altitude up to 2,000 meters is allowed to use the equipment.
3. All specifications are tested under 20°C ∼ 30°C except otherwise
stated.
4. The range of operation temperature is 0°C ∼ 40°C.
5. The relative humidity is from 10% to 90%. When in high humidity
To Next Page
