Programmable DC Electronic Load 63600 Series Operation & Programming Manual
6. Clear the Setting Sequenc
.
Clear the setting Sequences by turn the Rotary knob to change the display value to YES,
then press key to confirm.
7. Set the Amount of the Total Setting Sequenc
.
Set the Amount of the Total Setting Sequence by turn the Rotary knob to change the
display value, then press key to confirm the setting.
REMAIN_SEQ : 98
CLEAR_SEQ : NO
TOTAL_SEQ : 2
8. Setting Sequenc
.
In the page of Program Sequences Function, turn the Rotary knob to change the display
value to Sequence Setting, then press key into Sequence Setting page of
Program Sequences Function.
SET_SEQ
a. Setting the Sequence Mode
There are four modes to control the sequence execution.
SKIP: Skip the sequence. Load will not change input status.
AUTO: When Dwell time passes, the Load will get to the next sequence
automatically.
MANUAL: Press key to confirm, then the Load will get to the next sequence
automatically.
External: Use External signal of TRIG_ SEQ to control Load input on/off. When the
rising edge of the TRIG_ SEQ signal is action, the Load will get to the
next sequence automatically.
Turn the Rotary knob to change the display value to MANUAL, and then press
keys to set sequence 1 to manual mode. You must set more two sequence
settings for one program. The default setting is SKIP.
TRIG : MANUAL
b. Select the operation mode.
There are four operation modes for Program Sequences Function. They are CC, CR,
CV and CP modes. Turn the Rotary knob to change the mode until the desired
mode is displayed on the VFD. Then, press key to select mode and confirm
the setting.
MODE : CC
