Chroma 63600-2 User Manual

General Information
1-11
Accuracy *
4
*
5
0.1%+0.1%F.S.
0.1%+0.1%F.S.
Voltage Monitor
Bandwidth
20 kHz
20 kHz
Range
0~80V
0~150V
0~600V
0~6V
0~16V
0~80V
Output
0~10V
0~10V
Accuracy
0.5%F.S.
0.5%F.S.
Current Monitor
Bandwidth
20 kHz
20 kHz
Range
0~0.15A
0~1.5A
0~15A
0~0.8A
0~8A
0~80A
Output
0~10V
0~10V
Accuracy
0.5%F.S.
0.5%F.S.
Protection
Over Power
Yes
Yes
Over Current
Yes
Yes
Over Voltage
Alarm *
8
Yes Yes
Over
Temperature
Yes Yes
Reverse
Yes
Yes
Interface
USB
Standard
Standard
Remote
controller
Optional Optional
Ethernet
Optional
Optional
GPIB
Optional
Optional
System Bus
Master/Slave & Remote Controller
Master/Slave & Remote Controller
Others
Dout
No. of bits
2 bits per mainframe
2 bits per mainframe
Level - H
1.8V/3.3V/5V switchable
1.8V/3.3V/5V switchable
Level - L
<0.6V@Isink=10mA
<0.6V@Isink=10mA
Drive
Pull_up resistor = 4.7kΩ
Pull_up resistor = 4.7kΩ
Din (TTL Compatible)
No. of bits
2 bits per mainframe
2 bits per mainframe
External Trig. for Digitizing(TTL Compatible, Rising edge)
No. of bits
1 bit per mainframe
1 bit per mainframe
External Trig. for Auto Sequences(TTL Compatible, Rising edge)
No. of bits
1 bit per mainframe
1 bit per mainframe
Load ON - O/P
Level
TTL Compatible, Level, Active High
TTL Compatible, Level, Active High
Short ON - O/P
No. of channels
2 channels per 63600-1 mainframe
4 channels per 63600-2 mainframe
10 channels per 63600-5 mainframe
2 channels per 63600-1 mainframe
4 channels per 63600-2 mainframe
10 channels per 63600-5 mainframe
Level
TTL Compatible, Level, Active High
TTL Compatible, Level, Active High
General
Short circuit
Current *
6
Set to 100% of rated current
Set to 100% of rated current
Input
Resistance
(Load Off),
Typical *
12
366kΩ (80V)
600kΩ (150V)
2MΩ (600V)
60kΩ (6V)
150kΩ (16V)
700kΩ (80V)
Dimensions
(HxWxD)
142x86x514mm / 5.6x3.4x20.2 inch 142x86x514mm / 5.6x3.4x20.2 inch
Weight
5kg / 11 lbs
4.5kg / 9.9 lbs
Operating
Temperature
0~40°C 0~40°C
Storage
Temperature
-20~80°C -20~80°C
Power
Supply from mainframe
Supply from mainframe
EMC & Safety
CE
CE
