Chroma 63600-2 User Manual

Local Operation
4-9
High range  Middle range Low range goes back to High range
2. Select state A/B for single channel module
For single channel module, press the key to select state A or state B, then the
LED “A” or LED “B” above the key lights up. Select state A, by pressing the
key to select state A, then the LED “A” above the key lights up.
3. Set Current Level
There are 15,000 discrete steps from 0 to full scale in each range. Press the
key to enter into the editing mode. Turn the Rotary knob to change the display value to
500mA, then press key to confirm.
500.00 mA
The user may use or key to change the cursor position to different digit of
data, then turn the rotary knob to change the value of that digit.
If the user does not use or key to display the cursor, then resolution of the
value changes according to the rotary knob turning speed.
4. Set Slew Rate
There are 500 discrete steps in each range. Press the key to set slew rate of
rise. Turn the Rotary knob to change the display value to 30mA/μs, and the VFD
displays:
: 30.00 mA/μs
Then press
key to confirm the setting, and the slew rate settings change to fall
at the same time. Turn the Rotary knob to change the display value to 30mA/μs, and the
VFD displays:
: 30.00 mA/μs
Then press
key to confirm the setting, and the setting page change to Current
Level at the same time.
5. Set the second Current Level for single channel module
Press the key to select State B then the LED “B” above the key lights
up.
Turn the Rotary knob to change the display value to 100.00mA, then press key
to confirm.
100.00 mA
6. Review and update the values of the setting parameters
Review the values of the setting parameters by pressing key. Update them by
A/B
A/B
A/B
A/B
EDIT
ENTER
DATA
ENTER
ENTER
A/B
A/B
ENTER
DATA
