5�2�3�2�- ITIC curve
The screen shown in Figure 196 displays the ITIC curve of all events detected by the device.
Figure 196: ITIC curve�
Each ▲ indicates an event detected by the device.
>
>
<
<
varh
Q
Back
Main
menu
Figure 197: ITIC curve display menu�
Use the and keys to select the different options.
To conrm the selection, press the key.
The menu in the bottom area disappears after a few seconds. Click on the key to display
the lower area again.
Voltage variation (%Un)
