5�7�22�- EXPANSION MODULES�
The main setup screen of the expansion modules, shown in Figure 316, displays the Datalog-
ger module and all expansion modules connected to the device.
Note: See “7.- EXPANSION MODULES” to access the conguration of the connected expansion
modules.
Figure 316: Main setup screen of the expansion modules
5�7�22�1�- Conguration of the Datalogger module
Use the and keys to move to the different options and select the icon of the Datalog-
ger module.
Press the key to open the main setup screen of the Datalogger data storage module, Figure
317�
Figure 317: Main setup screen of the Datalogger module�
