Chapter 4 Setting Up and Managing Network Configuration
Network Device Group Configuration
4-30
User Guide for Cisco Secure ACS for Windows Server
78-14696-01, Version 3.1
Step 2 In the Network Device Groups table, click Not Assigned.
Tip If the Network Device Groups table does not appear, click Interface
Configuration, click Advanced Options, and then select the Network
Device Groups check box.
Step 3 Click the name of the network device you want to assign to an NDG.
Step 4 From the Network Device Groups list, select the NDG to which you want to assign
the AAA client or AAA server.
Step 5 Click Submit.
Result: The client or server is assigned to an NDG.
Reassigning a AAA Client or AAA Server to an NDG
To reassign a AAA client or AAA server to a new NDG, follow these steps:
Step 1 In the navigation bar, click Network Configuration.
Result: The Network Configuration page opens.
Step 2 In the Network Device Groups table, click the name of the current group of the
network device.
Step 3 In either the AAA Clients table or AAA Servers table, as applicable, click the
name of the client or server you want to assign to a new NDG.
Step 4 From the Network Device Group list, select the NDG to which you want to
reassign the network device.
Step 5 Click Submit.
Result: The network device is assigned to the NDG you selected.
