Chapter 8 Establishing Cisco Secure ACS System Configuration
IP Pools Server
8-64
User Guide for Cisco Secure ACS for Windows Server
78-14696-01, Version 3.1
Editing an IP Pool Definition
To edit an IP pool definition, follow these steps:
Step 1 In the navigation bar, click System Configuration.
Step 2 Click IP Pools Server.
Result: The AAA Server IP Pools table lists any IP pools you have configured,
their address ranges, and the percentage of pooled addresses in use.
Step 3 Click the name of the IP pool you need to edit.
Result: The name pool table appears, where name is the name of the IP pool you
selected. The In Use field displays how many IP addresses in this pool are
allocated to a user. The Available field displays how many IP addresses are
unallocated to users.
Step 4 To change the name of the pool, in the Name box, type the name (up to 31
characters) to which you want to change the IP pool.
Step 5 To change the starting address of the pool range of IP addresses, in the Start
Address box, type the lowest IP address (up to 15 characters) of the new range of
addresses for the pool.
Note All addresses in an IP pool must be on the same Class C network, so the
first three octets of the start and end addresses must be the same. For
example, if the start address is 192.168.1.1, the end address must be
between 192.168.1.2 and 192.168.1.254.
Step 6 To change the ending address of the pool range of IP addresses, in the End
Address box, type the highest IP address (up to 15 characters) of the new range of
addresses for the pool.
Step 7 Click Submit.
Result: The edited IP pool appears in the AAA Server IP Pools table.
