Cisco 7800 Series Accessories Guide

Table 15: Cisco Headset 730 Buttons
DescriptionNameCallout
Number
Skip forward and backward through music tracks.
Only available if you have the headset paired to a
device that can play music.
Skip music track
This is the right and left of the right cup
face.
1
Three position switch:
• AMB: Slide to the top to enable ambient mode.
• No ambient mode or noise cancellation: Middle
position.
• NC: Slide to the bottom to enable noise
cancellation.
AMB and NC button
This button is located on the back of the
right cup.
2
Press to play or to pause your music. Only available
if you have the headset paired to a device that can
play music.
Pause and Play
This is the center of the right cup and is
marked with a dot.
3
Displays red when you are on a call or if you have
pressed the Mute button on the headset when you
aren't on a call.
Presence LED
This LED is located on the face of the
cup on both the right and left cup.
4
Cisco IP Phone 7800 and 8800 Series Accessories Guide for Cisco Unified Communications Manager
21
Headsets
Cisco Headset 730 Buttons and Hardware

Cisco 7800 Series Specifications

General

Wireless	No
Video Support	No
PoE	Yes, 802.3af/at
Audio Codec Support	G.711, G.722, G.729, iLBC
Network Protocols	SIP, SDP, IPv4, IPv6, UDP, TCP, DNS, TFTP, HTTP, HTTPS, DHCP
Security Features	802.1X, TLS, SRTP
Power Options	PoE
Headset Port	3.5mm
Buttons	Line keys, navigation cluster, softkeys, mute, speakerphone, headset, volume control
Bluetooth	No
Ethernet Switch	Yes, 2-port 10/100/1000
USB Port	Yes, for headset (7875)
