Chapter 1 Using Express Setup
Starting Express Setup
1-8
Catalyst 3750 Switch Hardware Installation Guide
78-15136-03
Figure 1-6 Connecting the Switch and PC or Workstation Ethernet Ports
Step 5
Connect the other end of the cable to the Ethernet port on the PC or workstation.
Verify that the port status LEDs on both connected Ethernet ports are green.
Step 6 Wait approximately 30 seconds after the port LEDs turn green, and launch a web
browser on your PC or workstation.
Step 7 Enter the IP address 10.0.0.1, as shown in Figure 1-7, and press Enter.
Figure 1-7 Entering the IP Address
The Express Setup home page appears, as shown in Figure 1-8.
1 Switch 3 PC or workstation
2 Ethernet cable
Catalyst 3750
S
E
R
I
E
S
SYS
T
R
PS
MA
ST
R
S
TA
T
D
UPLX
SP
EED
STACK
M
O
D
E
1
3
X
1
4
X
2
3
X
2
4
X
1
X
2
X
1
1
X
1
2
X
1
97174
2
3
