Cisco WAP2000 Administration Guide

3
Cisco WAP2000 Wireless-G Access Point with Power Over Ethernet Administration Guide 5
Product Overview
This chapter describes the physical features of the Cisco WAP2000 Wireless-G
Access Point with Power Over Ethernet and includes the following sections:
• Front Panel, page 5
• Back Panel, page6
• Side Panel, page7
Front Panel
The LEDs on the front panel of the access point display information about network
activity.
POWER—(Green) Lights up when the access point is powered on.
PoE—(Green) Lights up when the access point is powered through an Ethernet
cable.
WIRELESS—(Green) Lights up when the wireless module is active on the access
point. The LED flashes when the access point is actively sending or receiving data
from a wireless device.

Cisco WAP2000 Specifications

General

Brand	Cisco
Model	WAP2000
Category	Wireless Access Point
Language	English
