Citizen CL-S400DT Technical Manual

Chapter 4 Troubleshooting
4-2. Troubleshooting
4-11 CL-S400DT
4-2-5. Operation Panel Problems
Symptoms Checks Remedies
LED does not light. 1. Is the “SA FFC LED” firmly connected
between the “SA Main PCB” (J3) and
the “SA LCD PCB” (J301)?
2. Is the “SA FFC LED” inserted upside
down?
3. Failure in the “SA LCD PCB”.
4. Failure in the control circuit.
1. Connect it firmly.
2. Insert it in the correct direction.
3. Replace the “SA LCD PCB”.
4. Replace the “SA Main PCB”.
No key works. 1. Is the “SA FFC LED” firmly connected
between the “SA Main PCB” (J3) and
the “SA LCD PCB” (J301)?
2. Is the “SA FFC LED” inserted upside
down?
3. Failure in the “SA LCD PCB”.
4. Failure in the control circuit.
1. Connect it firmly.
2. Insert it in the correct direction.
3. Replace the “SA LCD PCB”.
4. Replace the “SA Main PCB”.
Nothing appears on
the LCD.
1. Is the printer in Standby state (the
POWER LED is lit)?
2. Is the “SA FFC LED” firmly connected
between the “SA Main PCB” (J3) and
the “SA LCD PCB” (J301)?
3. Is the “SA FFC LED” inserted upside
down?
4. Is the FPC firmly connected between
the “SA LCD PCB” (J302) and the
LCD?
5. Failure in the “SA LCD PCB”.
6. Failure in the control circuit.
1. Press any key.
2. Connect it firmly.
3. Insert it in the correct direction.
4. Connect it firmly.
5. Replace the “SA LCD PCB”.
6. Replace the “SA Main PCB”.

Citizen CL-S400DT Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum printing width	104.1 mm
Ethernet LAN	No
RS-232 interface	Yes
Optional connectivity	Ethernet, Parallel
USB 2.0 ports quantity	1
Flash memory	8 MB
Internal memory	16 MB
Power requirements	110 - 220 V, 50/60 Hz
Core diameter	25 mm
Media thickness	0.0635 - 0.254 mm
Maximum label width	118 mm
Maximum media length	812.8 mm
Sustainability certificates	ENERGY STAR
Product color	Black
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	149 mm
Width	206 mm
Height	150 mm
Weight	2680 g
