Citizen CL-S400DT Technical Manual

Chapter 1 Specifications
1-2. Printable Area
1-7 CL-S400DT
1-2. Printable Area
The printable area of the printer is as follows:
When media is set to the printer, it must be aligned with the media guides at the left of the printing
mechanism. Though the available maximum media width is 118 mm (4.65"), there are unprintable
areas on both sides: 2.5 mm (0.10") width on the left side and 11.5 mm (0.45") width on the right
side.
The left side unprintable area applies for any size media.
Maximum media width: 118 mm (4.65")
104.0 mm (4.09”)
11.5 mm (0.45")
Reference edge
Unprintable area
Printable area
Media guides
Direction of media feed
2.5 mm (0.10")

Citizen CL-S400DT Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum printing width	104.1 mm
Ethernet LAN	No
RS-232 interface	Yes
Optional connectivity	Ethernet, Parallel
USB 2.0 ports quantity	1
Flash memory	8 MB
Internal memory	16 MB
Power requirements	110 - 220 V, 50/60 Hz
Core diameter	25 mm
Media thickness	0.0635 - 0.254 mm
Maximum label width	118 mm
Maximum media length	812.8 mm
Sustainability certificates	ENERGY STAR
Product color	Black
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	149 mm
Width	206 mm
Height	150 mm
Weight	2680 g
