Citizen CL-S400DT Technical Manual

Chapter 1 Specifications
1-3. Printing Position Accuracy
CL-S400DT 1-8
1-3. Printing Position Accuracy
By factory default, the printing start position is 2.5 mm (0.10") away from the left end of the media
and 1 mm (0.04") backward the leading edge of the label, U-shaped notch, or black mark.
2.5 mm (0.10") is the necessary value to avoid printing in the unprintable area as mentioned in "
1-2.
Printable Area".
The printing start position will deviate from the ideal position as follows:
1 ± 2 mm*
2
(0.04 ± 0.08")
Reference edge
(Paper guides)
Printable area
Direction of media feed
Ideal printing start position
Actual printing start position*
1
2.5 ± 1 mm*
3
(0.10 ± 0.04")
100 ± 2 mm*
4
(39.4 ± 0.08")
Maximum media width: 118 mm (4.65")
Unprintable area
2.5 mm
(0.10")
*1: Actual printing start position. May deviates from the ideal one in the indicated range.
*2: Deviation of vertical positioning when printing position is set to 0.
*3: Deviation of horizontal positioning when printing position is set to 0.
*4: Deviation of vertical printing position when 100 mm is specified from the printing start
position.
1 mm (0.04")
Unprintable area

Citizen CL-S400DT Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum printing width	104.1 mm
Ethernet LAN	No
RS-232 interface	Yes
Optional connectivity	Ethernet, Parallel
USB 2.0 ports quantity	1
Flash memory	8 MB
Internal memory	16 MB
Power requirements	110 - 220 V, 50/60 Hz
Core diameter	25 mm
Media thickness	0.0635 - 0.254 mm
Maximum label width	118 mm
Maximum media length	812.8 mm
Sustainability certificates	ENERGY STAR
Product color	Black
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	149 mm
Width	206 mm
Height	150 mm
Weight	2680 g
