Citizen CL-S400DT Technical Manual

Chapter 1 Specifications
1-1. General Specifications
1-3 CL-S400DT
1-1. General Specifications
Printing
Printing method Direct thermal
Main scanning line density: 203 dots/inch (8 dots/mm)
Sub-scanning line density: 203 dots/inch (8 dots/mm)
Resolution
Head 864 dots (effective dots: 832 dots)
Max. print width 104 mm 4.1 inch
Max. print length 812.8 mm 32 inch
Print density Print density is adjustable with software
Printing speed setting 6, 5, 4, 3 or 2 inches per second.
2-4 inches per second with optional peeler.
Print mode
Batch mode Normal printing (single or multiple sheets)
Tear off mode Feeds back media to the tear-off position after printing is completed.
Cut mode *
1
Prints while cutting at designated sheet units.
The following two kinds of cut mode operations are available.
• Backfeed
• Cut through
(Cut through refers to stopping present printing to cut the previously
printed label when it reaches the cut position. After cutting, printing
restarts but a gap may be created at the seam of the printing at this
time.)
Peel mode *
1
Peels labels from the liners after printing them.
Media
Types of media Roll, fanfold (continuous thermal media, thermal die-cuts, continuous
thermal tags, continuous thermal tickets)
Kinds of media Thermal-transfer media
Recommended media
*
2
Heat-transfer media: label media (150LA-1 Ricoh)
tag media (130LHB Ricoh)
Max. media width 118.0 mm 4.65"
Min. media width 19.5 mm 0.77"
Min. label width 19.5 mm 0.77"
Min. label pitch *
3
6.35 mm 0.25"
Max. media thickness 0.254 mm 0.01"
Max. media length 812.8 mm 32"
Min. media length 6.35 mm 0.25"
Min. media thickness 0.0635 mm 0.0025"
Max. external diameter: 127mm 5" Roll media diameter
Media core: 25.4 to 76mm
Min. media core external diameter
(when using label media): 50.8mm
1 to 3"
2"
*1: Options can be separately purchased.
*2: If you wish to use other media, please contact the shop where you bought this item.
*3: When a media pitch of less than 1 inch is used, activate the "Small Media Adjustment"
setting in the "Page Setup".

Citizen CL-S400DT Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum printing width	104.1 mm
Ethernet LAN	No
RS-232 interface	Yes
Optional connectivity	Ethernet, Parallel
USB 2.0 ports quantity	1
Flash memory	8 MB
Internal memory	16 MB
Power requirements	110 - 220 V, 50/60 Hz
Core diameter	25 mm
Media thickness	0.0635 - 0.254 mm
Maximum label width	118 mm
Maximum media length	812.8 mm
Sustainability certificates	ENERGY STAR
Product color	Black
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	149 mm
Width	206 mm
Height	150 mm
Weight	2680 g
