Chapter 2 Operating Principles
2-3. Operation Panel
2-39 CL-S400DT
(3) How to change the settings in Factory mode
- In Factory mode, DO NOT change the factory-set values unless you need to change
them, since there are essential items related to printing accuracy, etc.
- Do not turn OFF the power of the printer until you finish the adjustment. If it is
turned OFF, you need to repeat the adjustment from the beginning.
- The value adjusted here is retained until you change it with the same
procedure. Note that, even if you perform initialization by selecting “Test
Mode” main menu, “Factory Default” submenu and “Yes” in that order, the
changed value is not returned to the initial value set at the factory.
(3-1) Submenu table in Factory mode
The following table shows the submenus of “Factory Setup” main menu.
*1 “[Factory Mode Settings Menu name]” in “Submenu Name” column shows the name
that will be printed in “Factory Mode Settings”. (Refer to “
(2) How to print the Factory
Mode Settings menus”.)
*2 “+” shows that the object electrically moves forward/rightward. “-” shows that the object
electrically moves backward/leftward. 8 dots correspond to 1 mm (203 dots correspond
to 1”).
Submenu Name
[Factory Mode Settings
Menu name]
Adjustable Value
(Default Value)
Description
Init Thru Sen
Performs calibration of the transparent sensor
sensitivity (adjustable sensor). For details, refer
to “3-7-1 (2) Sensor sensitivity adjustment
(Factory mode)” in Chapter 3.
Init Refl Sen
Performs calibration of the reflective sensor
sensitivity (adjustable sensor). For details, refer
to “3-7-1 (2) Sensor sensitivity adjustment
(Factory mode” in Chapter 3.
Through Pos
[Through Sensor Position]
-256 to +256 dot
(+000 dot)
Electrically shifts the position of transparent
sensor (adjustable sensor) back and forth.
(-32 to +32 mm, -1.26 to +1.26”)
Reflect Pos
[Reflect Sensor Position]
-256 to +256 dot
(+000 dot)
Electrically shifts the position of reflective sensor
(adjustable sensor) back and forth.
(-32 to +32 mm, -1.26 to +1.26”)
Mach Tear Pos
[Machine Tear Position]
-256 to +256 dot
(+000 dot)
Electrically shifts the tear off position back and
forth. (-32 to +32 mm, -1.26 to +1.26”)
Mach Cut Pos
[Machine Cut Position]
-256 to +256dot
(+000 dot)
Electrically shifts the cutting position back and
forth. (-32 to +32 mm, -1.26 to +1.26”) (Optional)
Mach Peel Pos
[Machine Peel Position]
-256 to +256dot
(+000 dot)
Electrically shifts the peel position back and
forth. (-32 to +32 mm, -1.26 to +1.26”) (Optional)
Mach Hor Pos
[Machine Horizontal Pos.]
-16 to +32dot
(+008 dot)
Electrically shifts the head position to the right or
left side.
(-2 to +4 mm, -0.08 to +0.16”)
Caution
To Next Page
