- 123 -
fn = 8: Function 8 Defining Data by the Column Format to Character Code
Page of Work Area
GS ( E pL pH fn y c1 c2[x d1...d(y × x)]k
[Code] <1d>H<28>H<45>H pL pH fn y c1 c2 [x d1..d(y×x)]k
[Range] 5≤(pL + pH x256)≤65535
fn = 8
y = 2 (At selection of font C)
y = 3 (At selection of other than font C)
128≤c1≤c2≤255
0≤x≤12 (At selection of font A)
0≤x≤9 (At selection of font B)
0≤x≤8 (At selection of font C)
0≤d≤255
k = c2 – c1 + 1
[Outline] Defines the data in column format in units of character on the code page in RAM.
Operates only in printer function setting mode.
Data structure (9 x17)
d1 d4 ............................ d25
d3 d6 ............................ d27
bit7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
7
6
5
4 Bits 6 through 0 are
3 not character data
2
1
0
To Next Page
