- 185 -
• MSW5-2 Basic vertical calculation pitch
[Outline] Select the basic calculation pitch in the paper feed direction.
OFF (0) ON (1)
Line Pitch 360 406
ON (1) OPERATION: Basic vertical calculation pitch is set to 1/406 inch.
Line-feed length is 3.75mm by default.
OFF (0) OPERATION: Basic vertical calculation pitch is set to 1/360 inch.
Line-feed length is 4.23mm by default.
[Default] OFF (0) [360]
• MSW5-3 USB mode
[Outline] Select USB mode.
OFF (0) ON (1)
USB Mode Virtual COM Printer Class
ON (1) OPERATION: Operated as Printer class
OFF (0) OPERATION: Operated as virtual COM class
[Default] ON (1) [Printer Class]
• MSW5-4 Reserved [Fixed to OFF (0)]
• MSW5-5 Reserved [Fixed to OFF (0)]
• MSW5-6 Not defined [Fixed to OFF (0)]
• MSW5-7 Not defined [Fixed to OFF (0)]
• MSW5-8 Not defined [Fixed to OFF (0)]
MSW7
• MSW7-1 Baud rate
[Outline] Select baud rate which is serial interface communication condition.
Enabled if DSW1-1 OFF is set [following memory switch setting].
Setting Value
Baud Rate
1200bps,2400 bps, 4800 bps, 9600 bps,
19200 bps, 38400 bps, 57600 bps, 115200 bps
[Default] 19200 bps
